Aluminium foil, cigarette aluminium foil
Application
Cigarette packing after laminated with paper
Specification
1)Thickness: 0.006-0.007mm
2)Width:customization
3)Alloy: 1235
4)Temper: O
5)Treatment: Mill Finish
6)Core I.D.: 75/150mm or customization
7)Inner Core Materials: Steel, Aluminum Core
8)Type: Roll
9)Standard: GB/T3198-2003
Mechanical Properties
|
Alloy |
Temper |
Gauge(mm) |
Tensile testing |
|
Tensile Strength(Mpa) |
ElongationA/% (more than) |
|
1235 |
O |
0.006-0.007 |
50-70 |
≥2.0 |
Typical gauge (T)
|
Gauge range |
0.006-0.007mm |
Product Tolerance on Size
|
Dimension |
Gauge(%) |
Width(mm) |
|
Tolerance |
+/-5 |
+1, -0 |
Pin Requirement
|
Category |
Pin Counts（pcs/㎡）less than |
|
Gauge(mm） |
Aluminum Foil for Cigarette Packing |
|
0.006 |
1500 |
|
0.0065 |
600 |
|
0.007 |
600 |
