Mirror Aluminium Composite Panel

Mirror aluminium composite panel
Introduction
Mirror aluminium composite panel is a new type of aluminium composite material skinned with anodized aluminium mirror sheets.The bottom aluminium skin is chromate treated and polyester coated.Because of it's moden style and other features, the panel is more and more popular interior decoration material, especial for ceiling, kitchen, electrical appliances, furniture and so on.
Specification

Panel Thickness(mm)
2mm-8mm
Aluminium Skin Thickness(mm)
0.08mm-0.5mm
Width(mm)
1220mm-2000mm
Length(mm)
2440mm-8000mm

Feature
-Light weight, high strength, extreme rigidity, superior impact resistance,
-excellent surface flatness and smoothness ,
-heat insulation, sound insulation, fire-resistance,
-acid-resistance, alkali-resistance, good weatherproofing and non-resonance
-various uniform colors ,can be easily processed and fabricated, quickly installed,
-elegant and magnificent, good flexibility fits various designs,
-easily maintenance, simply cleaning
Application
-Building exterior wall cladding, Interior wall ,
- shop face decoration, billboards, signboards,
-ceiling, eaves, balconies, kitchen, bathroom ,
-galleries, partitions interior decorations, other Industrial usage.
Surface properties

Paint Thickness(micron)
Anodize
Pencil Hardness
2H
Toughness Of Coating
2T
Temperature Resistance
-500C+900C
Impact Strength(kg/cm2)
50
Boiling Water Resistance
boiling for 2 hours,No change
Acid Resistance
Immerse surface in 2% HC1 for 24hours,No change
Alkali Resistance
Immerse surface in 2% NAOH for 24hours,No change
Oil Resistance
Immerse surface in 20# engine oil for 24hours,No change
Solvent Resistance
Cleaned 100 times with Dimethylbenzene,No change
Cleaning Resistance
>1000 times no change
Thermal Expansion
2.4mm/m @1000C Temp difference
Peel Strength
Average 131N.mm/mm
Bending Strength
>100MPA
Bending Elastic Modules
>2.0*104MPA
Heat Distortion Temperature
>950C
